Parameters for electrical control
Controlling mode: Touch screen+PLC
Air source: Pure compressed air
Air wastage: Under 280NL/min
Liquid type: Industrial purified water
Liquid consumption: 300cc /hour
Liquid storage capacity: 800cc
Admission pipe/Drainpipe: ￠8 8 / ￠6 6
Specification of nozzle tray: Default 30 nozzles
Specification of cleaning nozzle: 0201 – 2512 (inch)
Noise: 35-60 dB
It can be used for Panasonic CM402 CM602 NPM-W2 Yamaha YV100 YS24 YSM100 I-pulse nozzles FUJI NXT and CP6 cp7. Samsung Hanwha nozzles JUKI KE2070 RS1 RX7 vacuum Hitachi GXH ceramic nozzle.
Drying function
With blow-dried. Drying is unscientific and will cause damage to the suction nozzle.
Metal vacuum ceramic nozzle washable
The height does not exceed 3.5mm and the diameter does not exceed 12mm. It can be washed and replaced with different fixtures.
Cleaning principle. Cleaning solvent and diluted alcohol.
The principle is high-pressure pulse (30PCS nozzle machines are flushed from top to bottom, 60PCS or 228PCS nozzle machines are 360 degrees rotation and ultrasonic vibration). You can add a little cleaning solvent and diluted alcohol when stubborn stains. As well as we have small ultrasonic cleaners for metal tooling spare part and sterilization.
