CM402 Servoamplificatore driver asse X KXFP6GE1A00 MR-J2S-40B-EE085

Sei qui: Casa » Prodotti » Ricambi SMT » Parti di posizionamento » PANASONIC » CM402 X Axis Driver Servo Amplifier KXFP6GE1A00 MR-J2S-40B-EE085
Codice prodotto: KXFP6GE1A00
Nome della parte: CM402 X Axis Servo Amplifier Driver
Tipo di modello: MR-J2S-40B-EE085
Peso: 2.5Kg (GW)
Marchio: Mitsubishi
Grandezza: 9*8*4 in
CM402 Servoamplificatore driver asse X KXFP6GE1A00 MR-J2S-40B-EE085

Mitsubishi AC servo amplifier MR-J2S-40B-EE085 used for Panasonic pick and place machine CM402 X axis and the part number is KXFP6GE1A00.
Rated output: 0.6chilowatt.
SSCNET interface.
Voltaggio: 3-phase AC200VAC or single-phase AC230V.
A fully synchronous system using SSCNET high-speed serial communication,
The communication cycle time between the controller and the servo amplifier is 0.888ms

Connectors are used for the servo amplifier terminal block, reducing the time required for wiring.
The connector is located on the front of the servo amplifier MR-J2S-40B-EE085 for easy cable connection.
Easy gain adjustment and improved reliability with real-time auto-tune function

Applications: Feed of processing equipment and machine tools.
For food, packaging equipment, and feeding devices. Used in textile machinery and SMT placement machines, it can improve the performance of the equipment.

Categoria: PANASONIC | Cartellino:
