Description:
Fluid medium: Air
Operation pressure range: -10~0kPa
Element Filtering accuracy: 5μm and trapping efficiency is up to 95%
Process temperature range: 0~60 degrees
Filtering area: 0.8mm²
Features and advantages:
Ejector and venting (vacuum break) functions are integrated.
By applying or stopping the supply of air to the ejector, it is possible to switch from vacuum generation to blowing air.
The ejector is equipped with air blowing (vacuum-breaking) function.
Reliable air blowing (vacuum break) is possible compared to traditional single stand-alone ejectors.
Compared with the traditional solenoid valve vacuum generator, the price has been greatly improved.
Small size and lightweight.Can be installed at the end of the vacuum circuit.
Configure the stop valve to achieve high suction and discharge cycle.
